    Garlic Dosing Mesh Bag Packing Machine

    Ask Lasest Price
    Brand Name : China
    Certification : CE, ISO9001
    Model Number : ROMITER
    Delivery Time : Within 20Days
    Payment Terms : T/T, Western Union
    Supply Ability : 30set Per Month
    Price : 0-99999
    • Product Details
    • Company Profile

    Garlic Dosing Mesh Bag Packing Machine

    Garlic-Dosing-Mesh-Bag-Packing-Machine

    Garlic Dosing Mesh Bag Packing Machine are designed for dosing of agricultural products (potatoes, onion, garlic, apply etc) into knitted sleeves, box pallets, bags or cases. The material shall be cleaned and sorted out for the operation to be smooth and trouble free. The minimum size of fruits is 20mm.the maximum size of fruits is 120mm. the average effective volume of the hopper in which a dose is weighed is 70 dm3 (this corresponds to 50 kg of potatoes of size of ca.70 to 90 mm). The weight of a dose can be adjusted by 0.01kg in the range of 5 to 50kg.

    The device can work as a last stage of an after-harvest assorting line, or it can work alone. One person is sufficient for its operation.

    garlic-mesh-bag-dosing-weight-packing-machine-final-package

    Working Process of Garlic Dosing Mesh Bag Packing Machine

    The pressure sensor sends the signal to the hopper to indicate the product weight. The electrical control unit receives data from pressure sensor, then it will automatically calculate and output the information, so as to control the weighing process. The belt operates based on the target weight, coarse filling, medium filling and fine filling.

    The sequence is : coarse filling-medium filling-fine filling, so that the target weight is reached. When in the coarse filling, the wider belt is in a high speed, while in medium filling, it will in a medium speed. Then coming the target weight, the wider belt will stop. On the process of coarse filling and medium filling, the narrow belt keeps running slowly, while on fine filling, it will fill the products one by one to stop until reaching the target weight.

    Feature of Garlic Dosing Mesh Bag Packing Machine

    1. Two conveyor belt is installed on the machine frame. Each conveyor belt is driven separately, and the data can be adjusted individually. The 0.3m belt is controlled by double operation speed electric reducer, so that the belt can convey the products into the hopper. The 0.1m belt is by low speed electric reducer. After the 0.3M belt stopped, it will get accurate measurement until the target weight.
    2. The hopper is installed in the bottom frame by a pressure sensor. There is a discharging door in the hopper, which is controlled by two cylinders for discharging and closure.

    Specification of Garlic Dosing Mesh Bag Packing Machine

    SpecificationsRM50
    Machine size2920*790*2170mm
    Net weight330KG
    Working conditionambient temperatures, not be affected by air conditions
    Running temperature+5℃-40℃
    Rated voltage3P 380VAC ±10%
    Control voltageDC24V
    Power2.2kw
    Air pressure0.8MPa
    Weighing range5-50KG
    Weighing adjusting0.01kg
    Dosing accuracyMore or less than the weight of one product
    Weight displayNumbers, four digits
    Weight display digit0.01kg
    Quantity displayNumbers, 0-9999
    Control moduleOne bag modus or pallet modus
    Noise grade77dB
    personnelone
    Speed

    5KG (based on the actual weighing products) reaches 280pcs/h

    50KG (based on the actual weighing products) reaches 110pcs/h

    General Drawing of Garlic Dosing Mesh Bag Packing Machine

    Garlic-Dosing-Mesh-Bag-Packing-Machine-Drawing

    1.PVC conveyor system 2. Drives of conveyor 3. Chassis 4. Hopper with tensometer 5. Exchangeable sack fillers

    6. electronic control unit 7. Electronic power box 8. Air inlet Φ8mm(in the back of electric power box)


    Working Video of Garlic Dosing Mesh Bag Packing Machine
